Model HBS-3 Hydraulic Brisket Saw

The Jarvis Model HBS-3 is a hydraulically powered brisket saw engineered for high-speed, accurate cutting of hog and sow briskets. With a capacity of up to 1,000 hogs per hour, the HBS-3 enhances production efficiency while ensuring consistent, clean cuts. Designed with a short overall length and lightweight construction, it provides superior maneuverability and handling, making it the ideal tool for high-volume meat processing facilities. Built with a heavy-duty stainless steel cutting head, the HBS-3 offers long-lasting durability and trouble-free operation. Advanced safety features, including anti-tie down controls and a fast blade stop, ensure operator protection while maintaining compliance with stringent hygiene and safety standards.

Key Features:
High-Speed Processing:
Capable of processing up to 1,000 hogs per hour, optimizing productivity and throughput.
Superior Maneuverability:
Short overall length and lightweight design with adjustable handles for optimal handling and control.
Heavy-Duty Durability:
Rugged stainless steel cutting head ensures long-term, reliable operation in demanding environments.
Enhanced Safety Features:
Equipped with anti-tie down controls and a fast blade stop for maximum operator protection.
Hygienic Construction:
Built from corrosion-resistant materials to meet national and international hygiene standards.

The Jarvis HBS-3 Hydraulic Brisket Saw is the ultimate solution for meat processing plants looking to enhance efficiency, durability, and operator safety in hog and sow processing operations. Its innovative hydraulic power system ensures consistent performance even in high-demand environments, reducing downtime and maintenance requirements.

Technical Specifications:
Drive:
Hydraulic

Capacity:
1000 cuts/hour

Blade Speed:
5.5 gal/min (20.8 L/min)
1925 rpm

Control Handles:
Electric / Dual Anti-tie Down (12 V)

Blade Diameters:
Hog: 8.0 in (203 mm)
Sow: 9.0 in (229 mm)

Cutting Depths:
Hog: 3.0 in (76 mm)
Sow: 4.0 in (102 mm)

Overall Length:
32 in (813 mm) with 8.0 in (203 mm) diameter blade

Weight:
30 lbs (13.4 kg)

Hydraulic Power Unit Specifications
Motor Power:
7.5 hp (5593 W)

Operating Voltage:
460 / 230 V, 3 phase, 60 Hz
Other voltages and 50 Hz available

Hydraulic Pressure:
2000 psi

Oil Flow Rate:
5.5 gal/min (20.8 L/min)

Hose Length:
16 ft (5 m)

Oil Capacity:
30 gal (114 L)

Overall Dimensions (L x W x H):
37.6 x 31.8 x 33.7 in (955 x 808 x 856 mm)

Weight (without oil):
410 lbs (186 kg)

Equipment Selection and Accessories
Model HBS-3:
Hog (with 8.0 in / 203 mm diameter blade) – Order No. 4007016
Sow (with 9.0 in / 229 mm diameter blade) – Order No. 4007017

Hydraulic Power Unit (with hydraulic hoses and control cable):
380 / 220 V, 3 phase, 60 Hz – Order No. 4027098
380 / 220 V, 3 phase, 50 Hz – Order No. 4027134
460 / 230 V, 3 phase, 60 Hz – Order No. 4027064
575 V, 3 phase, 60 Hz – Order No. 4027094

Balancer:
Order No. 4042046

Blades:
Hog (8.0 in / 203 mm diameter) – Order No. 1023203
Sow (9.0 in / 229 mm diameter) – Order No. 1023010
